Polyisoprene Rubber Gasket for IV Solution

Polyisoprene Rubber Gasket for IV Solution


Feature

20PP 25PP 30PP 12-Y SPC

1. Fit for large volume parenteral solution.
2. ISO9001 & ISO13485 &ISO15759 quality standard,and compliance with USP3.8.1 & Eur.Ph.3.2.9 standard。Fit for Europe IV infusion single head and double heads cap.
3. Excellent sealing performance and few fragments upon piercing.
4. Clearly defined dips that improve piercing precision and offer operational convenience.
5.ODM&OEM service is acceptable.
6.Various color ,packaging ,finishings choice,We can offer RTU(ready to use) RTS(ready to sterilise) packaging ,fit for autoclave and gamma sterilisation.
All th emain material rubber from Exxon Mobil.

Size

Item name Belly drum Dia. (mm) Edge Dia. (mm) Puncture thickness(mm) Height(mm)
φ25 24.7 21 2.5 7
24.3 2.5
φ20 21   2.9 5.5
φ30 30     4.9
12-Y 11.95-12.1 11.7 3 5.4
Item name Outer Dia. (mm) Outer Heigh(mm)  Center Height(mm)
SPC 14 5.05-5.55 6.4-6.95

Packaging

Item Thousand pcs/bag Thousand pcs/CTN KG/BAG N.W./CTN KG G.W.KG/CTN
12-Y 10 20 5.6 11.2 12.1
Φ20 5 10 8.2 16.4 17.5
Φ25 2.5 5 6.16 12.32 13.4
Φ30 2.5 5 9.25 18.5 19.6
